Blackmagic ATEM 4 M/E Constellation 4K
Product Code: 3099460

Blackmagic ATEM 4 M/E Constellation 4K

Special Order
This product is either directly despatched from our supplier or produced to order. Delivery usually takes at least 4 weeks. Order today and no payment will be taken until the item is in stock and ready to be despatched. Full details »

Thinking of upgrading? Trade in today

Configurations
Loading...
was: £9,486.00 £8,973.00
Please Login or Register to add to your Wish List.

Flexible Finance Options Available Finance options available

Spread the cost over 12, 24 or 36 months
Back to top

The Blackmagic ATEM 4 M/E Constellation 4K is a powerful UltraHD studio switcher designed for large-scale events, featuring 40 12G-SDI inputs, 24 12G-SDI outputs, and advanced keyers. This 2U rack-mounted switcher boasts an integrated Fairlight audio mixer and supports up to 2160p60 Ultra HD standards, part of the first range of audio-focused live production switchers

Blackmagic ATEM 4 M/E Constellation 4K Key Features:

  • Professional UltraHD studio switcher for large broadcast productions
  • Designed for concerts and stadiums with lots of coverage from many streams
  • Includes 40 12G SDI standards converted inputs and 24 12G SDI outputs
  • Advanced effects with 16 advanced chroma upstream keyers and 4 downstream keyers
  • Support for 4 UltraHD monitors with 16 views each with Multi View for 64 views
  • Source select and control buttons, control dial, mix controls, menu and lock buttons
  • Integrated Fairlight audio mixer with 156 channels and 6-band parametric EQ
  • Provides signal re-sync, frame rate and format converters on all video inputs
  • 2U rack-mounted design fits easily into existing production infrastructure
  • Powered by high-performance 2 SuperSource multi-view processors
  • Venue compatible supporting one in, two out stereo 32 channel MADI BNC
  • Talkback compatible with ClearCom and RTS for the routing of crew comms
  • Built-in HD LCD display for label, menu navigation and emergency switching
  • Processes output up to 2160p60 Ultra HD television standard

Expanded Blackmagic ATEM 4 M/E Constellation 4K Key Features:

Stadium Ready

The Blackmagic ATEM 4 M/E Constellation 4K is a complete UltraHD studio switcher for large broadcast productions, ideal for concerts, stadiums and other productions requiring extensive coverage. With 40 12G SDI standards converted inputs and 24 12G SDI outputs, the ATEM 4 M/E Constellation 4K gives you plenty of channels to work with.

It also features two high-performance SuperSource processors, allowing you to connect up to 4 UltraHD monitors with 16 views each and Multi-View for 64 views, making this switcher able to handle massive productions with multiple operators.

Advanced Effects

Using up to 4 independent DVEs (Digital Video Editing systems) powered by the two SuperSource processors, the ATEM 4 M/E Constellation 4K lets you layer multiple compositions from any view on the fly.

16 advanced upstream chroma keyers and 4 downstream keyers allow for removing whole scene backgrounds across multiple cameras, perfect for virtual production studios organising fixed and floating cameras in one powerful solution.

All-Out Audio

The Blackmagic ATEM 4 M/E Constellation 4K offers an integrated Fairlight audio mixer with an impressive 156 channels, providing an unparalleled live audio experience with the largest audio mixer available in a live production switcher, plus a 6-band parametric EQ for further sound shaping. It also supports one-in, two-out stereo 32-channel MADI BNC for use with existing studio audio setups and is compatible with ClearCom and RTS for talkback.

Production Compatible

The 2U rack-mounted Blackmagic ATEM 4 M/E Constellation 4K integrates seamlessly with your pre-existing production infrastructure. With its source select and control buttons, control dial, talkback and mix controls, and menu and lock buttons, you can effortlessly switch between sources, adjust audio levels, and access menus quickly and safely.

Industry Standard Technolgy

Ensure your broadcast productions are up to the mark with the Blackmagic ATEM 4 M/E Constellation 4K. This UltraHD studio switcher is perfect for large-scale broadcast productions and features signal re-sync, frame rate and format converters up to the highest 2160p60 Ultra HD television standard. The Blackmagic ATEM 4 M/E Constellation 4K enhances any broadcast workflow.

What’s in the box?

  • 1 x ATEM 4 M/E Constellation 4K
  • 1 x QR Code For Software Download

FAQs:

Who is the ATEM 4 M/E Constellation 4K for?

Due to its large amount of inputs and processing power, the ATEM 4 M/E Constellation 4K is ideal for studios with a stadium or sports event worth of live footage to sort. Fitting within existing production racks with a 2U design for use in production vans, control rooms etc.

How do I power the Blackmagic ATEM 4 M/E Constellation 4K?

Using two internal 100-240V AC 50/60Hz power supplies, the ATEM 4 M/E Constellation 4K requires 2 C13 (Kettle Lead) UK AC power cables (Not Included).

What are the audio connections of the Blackmagic ATEM 4 M/E Constellation 4K?

The audio inputs of the ATEM 4 M/E Constellation 4K are:

  • 1 x BNC 32 Ch MADI digital audio
  • 1 x 5-pin Talkback XLR
  • 2 x 1/4 inch balanced jack
  • Embedded on all 40 SDI inputs

The audio outputs of the Blackmagic ATEM 4 M/E Constellation 4K are:

  • 2 x BNC 32 Ch MADI digital audio
  • 1 x 5-pin Talkback XLR
  • 2 x 1/4 inch balanced jack
  • Embedded on all 24 SDI outputs

What systems is Blackmagic ATEM 4 M/E Constellation 4K compatible with?

The Blackmagic ATEM 4 M/E Constellation 4K is compatible with ATEM Advanced Panels for multichannel manual switching, ATEM Camera Control Panel for remote multicam control, GPI and Tally Interface for tally data, ATEM Software Control or a Mackie compatible panel for audio mixing and more for
