Datavideo Robotic Pan/Tilt head with HDBaseT UHD
Datavideo's latest release, PTR-15, a 4K 12G-SDI robotic pan tilt head with FreeD functionality. It employs an efficient driving system to achieve smooth and precise robotic pan and tilt movements. It can be paired with most models of broadcast-grade cameras available in the market, enabling remote control of camera parameters such as pan, tilt, zoom, and aperture. The PTR-15 comes equipped with the built-in FreeD virtual tracking feature, which utilises computer vision sensor technology to recognise and track the position and movements of the subject being filmed. The PTR-15 can be controlled using an IR controller, VISCA protocol controller, Datavideo RMC-180 MARK II camera controller, RMC- 300A universal remote control panel, and is compatible with both serial and Ethernet (DVIP) connections.
Datavideo Robotic Pan/Tilt head with HDBaseT UHD Key Features:
- 4K Robotic Pan Tilt Head
- Versatile Signal Connectivity
- Wide Range of Compatible Cameras Supported
- Light Weight, Strong and Sturdy Design
- Supports Cameras up to 4Kg
- Dual 12G-SDI and HDMI 2.0 Interfaces
- Genlock/Timecode Synchronization and Calibration
- Comprehensive IP Control
- Seamless PoE++ Integration
- Built-in Tally Light
Expanded Datavideo Robotic Pan/Tilt head with HDBaseT UHD Key Features:
Versatile Signal Connectivity
The PTR-15 boasts an extensive range of signal interfaces for seamless integration with the remote head. These interfaces encompass SDI, HDMI, RS-232, RS-422, DVIP, Tally, and LANC, providing diverse connectivity options.
Cost-Effective Transition to Remote PTZ Control
With PTR-15, transitioning from conventional camcorder cameras to remote-controlled PTZ becomes a cost-effective solution. The system empowers a single operator to efficiently manage multi-camera remote operations.
Free-D Virtual Studio Camera Position Awareness System Communication
Datavideo's PTR-15 robotic pan tilt head combines advanced pan-tilt technology with AR/VR systems. It interfaces via RS-422 to transmit pan, tilt, and zoom data to the TVS-3000 Virtual Studio Production System, ensuring seamless collaboration. For different cameras and lenses, it supports lens tracking data acquisition via ZEK-1 or ZEK-2 sensors, enabling lens zoom control and motor tracking synchronization. The RS-422 output provides 8-bit precision Free-D protocol tracking data, compatible with most virtual systems. It offers precise pan (±340 degrees) and tilt (±45 degrees) control with adjustable motion trajectories and speeds, achieving high precision. Built on Datavideo's DVIP protocol, it's compatible with TCP/IP network protocols, supporting third-party device control. You can choose the RMC-300A IP control panel with a 5-inch UI touchscreen or the RMC-180 MARK II serial control panel for dual-system control, enhancing security and reliability.
Comprehensive IP Control
In addition to the standard RS-232/422 control, the PTR-15 provides robust IP-based control, keeping up with the modern trend of IP-based systems. This technology migrates the camera control protocols and technical parameter adjustments used in high-end broadcast studios to an open IP environment. This transformation breaks away from the previous limitations of exclusive one-to-one control, enabling the free switching of different cameras and achieving precise adjustments of camera parameters such as aperture, shutter, red/blue gain, inflection point, and more. This advancement allows on-site camera operations to enter an unprecedented era of convenience.
What's in the box?
- 1 x PTR-10T Mark II Main Unit
- 1 x DC 12V Power Adaptor
- 1 x AC Cord
- 1 x IR Remote Control
- 1 x DC With Lock To D-Tap Cable
- 1 x HDMI Cable
- 1 x SDI Cable
- 1 x Remote Cable (2.5mm Phone-Jack To Mini-Din 8pin)
- 2 x 1/4” Screw
- 1 x 1/4” To 3/8” Screw Adaptor
Product Specification
Dimensions | 230 x 190 x 300 mm |
Included Accessories | 1 x DC 12V Power Adaptor 1 x AC Cord 1 x IR Remote Control 1 x DC With Lock To D-Tap Cable 1 x HDMI Cable 1 x SDI Cable 1 x Remote Cable (2.5mm Phone-Jack To Mini-Din 8pin) 2 x 1/4” Screw 1 x 1/4” To 3/8” Screw Adaptor |
Outputs | HDMI x 1 SDI x 1 RJ45 x 1 (HDBaseT) |
Panning|Tilting Range | Pan: 340° Tilt: ±45° |
Panning|Tilting Speed | Pan: 0.12~15° /Sec Tilt: 0.06~10° /Sec |
Remote Control Interface and Transmit Distance | 1,200M by RS422, 100M by HDBaseT, Sony VISCA, DVIP |
Weight [g] | 3400.00 |
