Swit S-1093F LUX - 9-inch On camera LCD monitor with Luxury package no plate
Product Code: 3121869

Swit S-1093F LUX - 9-inch On camera LCD monitor with Luxury package no plate

£1,486.00 Special Order
Spread cost over 12, 24 or 36 months
>
Paypal Pay in 3
Pay in 3 interest free payments
>
Back to top

The Swit S-1093F LUX – 9-inch On-camera LCD Monitor is a practical solution for broadcasting and filmmaking purposes. It comes with a 1920x1200 display and a 170° wide viewing angle for crisp and sharp results. This monitor has 16-ch embedded audio metres to allow 16 channels simultaneously. Its LCD screen has a protective glass for maximum safety against breakage and scratches.

Swit S-1093F LUX - 9-inch On-camera LCD Monitor with Luxury Package (No Plate) Key Features:

  • Ideal choice for filmmaking and broadcasting purposes
  • LCD display with a 1920×1200 resolution for crisp and sharp results
  • 170° wide viewing angle for accurate results from every direction
  • Supports various video input formats including 2K, 3G, HD, and SD-SDI, HDMI, & CVBS
  • 16-channel embedded audio meters to monitor every audio
  • Flexibility to select any two audio channels for output
  • Visual aids such as waveform displays in Y/Cb/Cr/R/G/B and single-line formats
  • AFD, H/V delay, R/G/B/Mono, and false colour for advanced video analysis
  • Supports TSL UMD and text TALLY display to enhance production monitoring capabilities
  • Zebra stripes and peaking focus assist for improved focusing during shooting
  • 4:3, 13:9, 14:9, 15:9, 1.85:1, and 2.35:1 aspect markers for proper framing & composition
  • 4:3, 13:9, 14:9, 15:9, 1.85:1, and 2.35:1 aspect markers for proper framing & composition

What's in the box?

  • 1 x Swit S-1093F LUX - 9-inch On-camera LCD Monitor with Luxury Package (No Plate)
  • 1 x Cold shoe and 1/4" Arm Trestle
  • 1 x S-7004 Battery Plate
  • 1 x AC-DC Adapter
  • 1 x Sun Hood

FAQs:

What is the resolution of this Swit monitor?

The Swit on-camera monitor has a resolution of 1920x1200.

Does the Swit S-1093F monitor come with a protective cover?

The monitor LCD comes with a protective glass for safety against scratches, damage and defect.

Which video formats are supported by the monitor?

The monitor supports various video formats including 2K, 3G, HD, and SD-SDI, HDMI, and CVBS.

What is the purpose of peaking focus assist?

The peaking focus assist and zebra stripes help improve the focus during video shoots.

Is firmware update possible in this Swit 9-inch LCD monitor?

The Swit monitor supports firmware updates via the provided standard USB.

Back to top

Product Specification

Audio Monitoring Yes
Brightness 450cd/m2
Connections 2 x 2K/3G/HD/SD-SDI loop output, 1 x BNC, 1 x HDMI, 1 x 3.5mm SDI, HDMI, Analog audio output
Contrast Ratio 1000:1
Dimensions H24.1 x W17.8 x D5 cm
Included Accessories 1 x Cold shoe and 1/4" Arm Trestle, 1 x S-7004 battery plate (S/A/U/F/D/B/V/I/C/E selection), 1 x AC-DC Adaptor, 1 x Sun hood
Monitor Features All Waves, Vector Scope, Histogram
Power Consumption ≤18W
Power Options DC / battery 6.5V-24V
Recording Formats and Framerates 2048×1080p (60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 / 23.98) 1080p (60 / 59.94 / 50) 1080i (60 / 59.94 / 50) 1080p (30 / 29.97 / 25 / 24 / 23.98) 1080psf (30 / 29.97 / 25 / 24 / 23.98) 720p (60 / 59.94 / 50) 480i (59.94) 576i (50) 480i/ 576i / 480p / 576p 1080i (60 / 59.94 / 50) 720p (60 / 59.94 / 50) 1080p (60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 / 23.98) 1080psf (30 / 29.97 / 25 / 24 / 23.98)
Resolution 1920x1200
Screen Size 9 Inches
Weight 960g
Manufacturers Link Swit
