DJI Ronin 2 3-Axis Handheld Gimbal Professional Combo
Product Code: 1627463

DJI Ronin 2 3-Axis Handheld Gimbal Professional Combo

We no longer sell this product and will not be receiving any new stock. Check below for availability of second-hand units.

Condition Availability
New Discontinued - we can no longer source new stock of this product
Loading Alternatives
View all used versions of the DJI Ronin 2 3-Axis Handheld Gimbal Professional Combo currently available »
Back to top

The powerful DJI Ronin 2 3-Axis Handheld Gimbal is the next step in DJI's gimbal innovation. Featuring upgraded high-torque motors, a new detachable grip, and 'Enhanced Intelligence' the Ronin 2 has been engineered for reliability, efficiency, and ease of use. Compatible with more devices than ever before, the Ronin 2 can also resist high G-forces, ensuring unrivalled smoothness.

Key Features: DJI Ronin 2 3-Axis Handheld Gimbal

  • Unprecedented power: Upgraded high-torque motors allowing for more compatibility than ever before, ensuring smoothness even in high wind situations
  • Detachable grip: Remove the lower part of the hand grip when not needed
  • Simplicity: Refined and tweaked controls make setup easier than ever
  • 'Enhanced Intelligence': Get shots that would never have been possible without more specialist equipment

DJI Ronin 2 Hands-on | Test Footage | The Best Gimbal Out There?

Specifications:

General:

  • Operation modes:
    • Underslung mode
    • Upright mode
    • Briefcase mode
    • Handheld, car mount, aerial, tripod, & Steadicam mode
  • Built-in, independent IMU module
  • DJI Advanced 32-Bit ARM processor
  • DJI specialised gimbal drive motors with encoders
  • Dual battery system
  • Bluetooth module
  • D-Bus receiver support
  • 2.4/5.8GHz receiver
  • Temperature sensors
  • Built-in touch panel
  • Built-in GPS
  • USB type-C connection
  • Power and video signal through slip ring
  • Included in your purchase:

    • Ronin 2 Gimbal
    • Carrying case
    • Ronin 2 Power hub
    • Camera mounting plate
    • Camera upper mounting plate
    • Remote controller
    • Battey compartment
    • Intelligent battery (TB50)
    • Battery charger
    • Power cable
    • Charging hub
    • Grip
    • Accessories package:
      • Screw and hex keys
    • Cable package:
      • Red power
      • Arri power
      • 2-pin power
      • DC power
      • 6-pin-to-P-tap adapter
      • USB-C cable
      • Control cable (red)
      • Control cable (Arri)
      • Ronin 2 power cable
      • S-bus receiver cable
    • Manual package
    • Monitor mount bracket
    • 15 mm rod mount
    • 15 mm extension rod
    • Ronin 2 universal mount

    Peripheral:

    • Camera tray dimensions:
      • Maximum depth from centre of gravity on camera base plate: 245mm
      • Maximum height measures from top of the camera base plate: 165mm
      • Maximum width: 180mm
    • Accessory power connections:
      • 14.4V x 4 camera cage (combined 8 A)
      • 12.6V x 2 pan motor (combined 4 A)
      • 12.6V x 1 P-Tap (8 A)
    • GCU Power Unit: Intelligent Battery 4280mAh-22.8V
    • Connections: 2.4/5.8GHz remote control, Bluetooth 4.0, USB Type-C

    Mechanical & Electrical Characteristics:

    • Working current:
      • Static current: 300mA (A22.8V)
      • Dynamic current: 500mA (@22.8V)
      • Locked motor current: Max 15A (@22.8V)
    • Run time: 8 hours (2.5 hours when powering gimbal and accessories)
    • Weight: 5.5kg (including handle bar) - 4.2kg (without handle bar)
    • Gimbal dimensions:
      • Including handle bar: 350 x 416 x 530mm
      • Excluding handle bar: 630 x 416 x 720mm
    • Working performance:

      • Load weight: 13.6 kg
      • Angular vibration range: 0.02°
      • Maximum controlled rotation speed:
        • Pan axis: 400°/s
        • Tilt axis: 360°/s
        • Roll axis: 360°/s
      • Mechanical endpoint range:
        • Pan axis control: 360° continuation rotation
        • Tilt axis control: +135°
        • Roll axis control: +220°
      • Controlled rotation range:
        • Pan axis control: 360° continuation rotation
        • Tilt axis control: +45° - 135°
        • Roll axis control: +45°
    Back to top

    Product Specification

    Accessory Power Connections 14.4 V x 4 Camera Cage (Combined 8 A), 12.6 V x 2 Pan Motor (Combined 4 A), 12.6 V x1 P-Tap (8 A)
    Angular Vibration Range ± 0.02°
    Controlled Rotation Range Pan axis control: 360° continuous rotation / Tilt axis control: +45° to -135° / Roll axis control: ±45°
    Dimensions 350 x 416 x 530 mm
    Input Power Intelligent Battery: 4280 mAh-22.8 V
    Load Weight 30 lbs (13.6 kg)
    Max Load [g] 136000
    Maxium Controlled Rotation Speed Pan axis: 400°/s, Tilt axis: 360°/s, Roll axis: 360°/s
    Mobile Software Requirements iOS 9 or above; Android 4.4 or above
    Operating Temperature -4°F ~ 122°F (-20°C ~ 50°C)
    Operational Modes Underslung Mode, Upright Mode, Briefcase Mode, Handheld, Car Mount, Aerial, Tripod, & Steadicam Mode
    PC Software Requirements Windows 7 or above; Mac OS X 10.11 or above
    Supported Camera Dimensions Maximum depth from the center of gravity on camera base plate: 245 mm, Maximum height measured from top of the camera base plate: 165 mm, Maximum width: 180 mm
    Type Gimbal
    Weight 12 lb (5.5 kg)
    Weight [g] 5500.00
    Working Current Static current: 300 mA (@22.8 V), Dynamic current: 500 mA (@22.8 V), Locked motor current: Max 15 A (@22.8 V)
